Strawberry candle mold

A strawberry candle, 76 mm tall: a plump berry with raised seeds, a star of leaves on top and a stem. A rigid two-part print.

Make your own candle mold
3D render of a red strawberry candle with raised seeds and green leaves between the two printed halves of its rigid blue and orange mold
Candle wax ~336 g Pro early access

A strawberry candle 76 mm tall and 68 mm across: a plump heart-shaped berry with raised seeds over the front and back, a five-pointed star of leaves on its shoulders and a short stem the wick comes out of. The tip is cut flat so it stands.

Read more

The mold is exactly what our two-part candle mold generator builds for it: two rigid halves with rubber-band grooves, pry pockets and a pour funnel on top. The seam runs down the sides of the berry, where there are no seeds, and the tool's own seam check finds nothing stuck. No silicone needed.

Fruit candles sell all year, strawberries most of all in spring and summer. Pour it red and paint the leaves green, or pour it in pastel pink. The zip carries both halves, the strawberry master as its own STL, the tool's own print-settings sheet and a recipe file for the generator.

Shown as a 3D render of the printed mold halves pulled apart around the candle they cast, not a photo.

What you need

3
  • About 138 g of pillar wax: the cavity holds 154 ml
  • A tabbed, primed wick for a 55 mm candle, about 90 mm long
  • Rubber bands or clamps, and a clip or wick bar across the funnel

How to cast it

5

  1. Print both halves as exported. Clamp-strength settings: 4 walls, 40% gyroid infill, no supports.

  2. Drop a tabbed wick into one half so the tab sits on the cavity floor, close the halves and band them along the whole seam.

  3. Clip the wick centred across the pour funnel and pour at 65 to 75 C.

  4. Once the first pour is firm but still warm, top up the funnel. Wax shrinks, and the second pour fills the dip.

  5. Cool fully, open the halves at the pry pockets and trim the wick just above the stem. Paint the leaves green if you like.

Print details

11 h 10 minPrint time
~336 gFilament
2Printed parts
80 × 88 × 97 mmSize (W x D x H)
All print details
Print details
Cast materialCandle wax
Printed parts2
Size (W x D x H)80 x 88 x 97 mm
Print bed needed88 x 41 mm, 97 mm tall
Filament~336 g
Layer height0.2 mm
Infill40%
SupportsNot needed
DownloadZIP: 2 printed parts (STL) + candle master (STL) + print sheet + recipe
Added2026-09-25

Pro early access until October 25, 2026, then free with any account.

Make your own candle mold →

Made with the free Rigid box mold generator. Upload your own model and get the same kind of mold built around it, in your browser.

Free for personal use. Selling the pieces you cast needs a commercial licence (Pro or Founder); passing on the file itself is not permitted on any plan. Full terms.

New to casting? Read the candle mold guide.

strawberry candle moldfruit candle moldstrawberry candlesummer candle moldtwo part candle mold

Questions about this design

Why are there no seeds down the sides of the strawberry?

The mold splits down the sides. Raised seeds right on that line would be smeared into bars by a rigid split, so they are on the front and the back only. From any normal viewing angle the berry looks seeded all over.

How do I colour the strawberry candle?

Pour it in red, then paint the leaves and stem green and dab the seeds with a pale yellow once it is cool. Or pour it in a soft pink and leave it plain for a pastel look.

Does the strawberry go with the other fruit candle molds?

Yes, it is the same scale as the apple, pear and lemon candle molds, so together they make a fruit bowl set.
