◆ Candle wax

David eye cube candle mold

A 70 mm cube candle carrying the eyes of Michelangelo's David, from a museum scan. A rigid two-part print, no silicone.

Make your own candle mold Download free on Thingiverse
3D render of a white cube candle with the eyes and brows of Michelangelo's David in relief, between the two printed halves of its rigid blue and orange mold
Candle wax ~238 g

A cube candle 70 mm on every side, its edges rounded to 5 mm, with the eye region of Michelangelo's David rising out of the front face: the heavy brows, both eyes and the top of the nose, 66 mm across. It is the classical, Renaissance look that fills candle boards on Pinterest, cut down to a shape that stands square on a shelf.

Read more

The relief is not a remodel. It is cut from SMK's 3D scan of a plaster cast of the Head of David (object KAS2232 in the Royal Cast Collection of the National Gallery of Denmark), which SMK publishes under the Public Domain Mark, so you can sell what you cast.

The mold is exactly what our two-part candle mold generator builds for it: two rigid halves with rubber-band grooves, pry pockets and a pour funnel on top. The relief rises out of a flat face that pulls straight away from the front half, so the brows and lids come out as sculpted, and the tool's own seam check finds nothing stuck. No silicone needed.

Pour it in white or bone and it reads like a piece of plaster from a cast gallery; a soft grey or terracotta suits it too. It pairs with the David lips cube. The zip carries both halves, the cube master as its own STL, the tool's own print-settings sheet and a recipe file for the generator.

Shown as a 3D render of the printed mold halves pulled apart around the candle they cast, not a photo.

David eye cube candle mold at a glance: every printed part with its size, print time, filament, print settings and the three steps to use it
How this mold works

What you need

3
  • About 298 g of pillar wax: the cavity holds 332 ml
  • A tabbed, primed wick for a 70 mm candle, about 100 mm long
  • Rubber bands or clamps, and a clip or wick bar across the funnel

How to cast it

5

  1. Print both halves as exported. Clamp-strength settings: 4 walls, 40% gyroid infill, no supports.

  2. Drop a tabbed wick into one half so the tab sits on the cavity floor, close the halves and band them along the whole seam.

  3. Clip the wick centred across the pour funnel and pour at 65 to 75 C.

  4. Once the first pour is firm but still warm, top up the funnel. Wax shrinks, and the second pour fills the dip.

  5. Cool fully, then open the halves at the pry pockets. The eyes come out of the front half. Trim the wick and buff the seam round the sides with a nylon stocking.

Print details

8 hPrint time
~238 gFilament
2Printed parts
86 × 91 × 91 mmSize (W x D x H)
All print details
Print details
Cast materialCandle wax
Printed parts2
Size (W x D x H)86 x 91 x 91 mm
Print bed needed91 x 45 mm, 91 mm tall
Filament~238 g
Layer height0.2 mm
Infill40%
SupportsNot needed
DownloadZIP: 2 printed parts (STL) + candle master (STL) + print sheet + recipe
Added2026-10-01
Make your own candle mold →

Made with the free Rigid box mold generator. Upload your own model and get the same kind of mold built around it, in your browser.

Download free on Thingiverse

Free download. Opens the Thingiverse listing in a new tab.

Free for personal use. Selling the pieces you cast needs a commercial licence (Pro or Founder); passing on the file itself is not permitted on any plan. Full terms.

New to casting? Read the candle mold guide.

david candle moldstatue face candlerenaissance candle moldaesthetic cube candletwo part candle mold

Questions about this design

Is the David eye cube candle cut from the real statue?

It is cut from a 3D scan of a plaster cast of David's head held by SMK, the National Gallery of Denmark (object KAS2232). Casts like it were taken from the marble for art academies. SMK releases the scan under the Public Domain Mark, so the relief and your candles are free to use and sell.

Why does the David eye cube candle need no silicone?

The eyes and brows rise out of a flat front face and every part of them faces the way the front half pulls away, so nothing hooks the print. The tool runs a seam check before it builds the mold and found nothing stuck. Pour at the low end of the range for the crispest lids.

How do I give the David eye cube candle an aged plaster look?

Pour it white, let it cool fully, then dry-brush a little grey or brown mica mixed with a drop of melted wax into the creases round the eyes and wipe the high points clean with a paper towel. The brows and lids stand out like an old cast.
