◆ Candle wax

Ribbed Christmas bauble candle mold

A 72 mm Christmas bauble candle with twelve rounded bands and a beaded ornament cap. A rigid two-part print.

Make your own candle mold
3D render of a deep red ribbed Christmas bauble candle with its ornament cap between the two printed halves of its rigid orange and blue mold
Candle wax ~350 g Pro early access

A bauble candle 72 mm across and 77 mm tall: a ball wrapped in twelve rounded bands like old pressed glass, fading out at the top and the foot, an ornament cap with a bead and a rim on top where the wick comes out, and a small flat underneath so it stands.

Read more

The mold is exactly what our two-part candle mold generator builds for it: two rigid halves with rubber-band grooves, pry pockets and a pour funnel on top. The bauble is turned, a profile spun round its axis, so a seam straight through its middle releases it cleanly and the tool's own seam check finds nothing stuck. Unlike a smooth sphere, the bands catch the light from every side.

A Christmas table candle: pour it in deep red, forest green or white and brush gold mica over the cap, or make a set in three colours for a gift box. The zip carries both halves, the bauble master as its own STL, the tool's own print-settings sheet and a recipe file for the generator.

Shown as a 3D render of the printed mold halves pulled apart around the candle they cast, not a photo.

What you need

3
  • About 174 g of pillar wax: the cavity holds 193 ml
  • A tabbed, primed wick for a 70 mm candle, about 110 mm long
  • Rubber bands or clamps, and a clip or wick bar across the funnel

How to cast it

5

  1. Print both halves as exported. Clamp-strength settings: 4 walls, 40% gyroid infill, no supports.

  2. Drop a tabbed wick into one half so the tab sits on the cavity floor, close the halves and band them along the whole seam.

  3. Clip the wick centred across the pour funnel and pour at 65 to 75 C.

  4. Once the first pour is firm but still warm, top up the funnel. Wax shrinks, and the second pour fills the dip.

  5. Cool fully, open the halves at the pry pockets and trim the wick. Brush gold or silver mica over the cap.

Print details

11 h 40 minPrint time
~350 gFilament
2Printed parts
84 × 93 × 98 mmSize (W x D x H)
All print details
Print details
Cast materialCandle wax
Printed parts2
Size (W x D x H)84 x 93 x 98 mm
Print bed needed93 x 43 mm, 99 mm tall
Filament~350 g
Layer height0.2 mm
Infill40%
SupportsNot needed
DownloadZIP: 2 printed parts (STL) + candle master (STL) + print sheet + recipe
Added2026-09-25

Pro early access until October 25, 2026, then free with any account.

Make your own candle mold →

Made with the free Rigid box mold generator. Upload your own model and get the same kind of mold built around it, in your browser.

Free for personal use. Selling the pieces you cast needs a commercial licence (Pro or Founder); passing on the file itself is not permitted on any plan. Full terms.

New to casting? Read the candle mold guide.

bauble candle moldchristmas ornament candlechristmas candle moldribbed ball candle moldtwo part candle mold

Questions about this design

How do I paint the cap on the bauble candle gold?

Once the candle is cold, brush gold mica mixed with a drop of melted wax onto the cap, or dip just the cap into a little pot of gold-tinted wax. Both stay put and burn cleanly; candle paint works too, but keep it off the wick.

Where does the wick go in the bauble candle?

Up the middle and out through the cap, where the pour funnel sits. Drop a tabbed wick in so the tab rests on the small flat at the bottom, close the halves and clip the wick centred across the funnel.

Why do the bands on the bauble candle not lock the mold?

Because they run round the ball, not up and down it. A band that circles the axis is cut in half by the seam and each half lifts straight out of its side of the mold. Vertical ribs would hook the halves, which is why ribbed spheres usually need silicone.
